Fire-resistant loft ladder FIRE PRO REI45
Fire-resistant loft ladder withstand fire for 45 minutes
Product description
Fire-resistant loft ladder from SOGEM
FIRE PRO REI 45 has a fire-resistance of 45 minutes and complies with EN 13501-2. The trapdoor is insulated with 50 mm rockwool plate, which is made of non-combustible, moisture and water-repellent Rockwool stone wool. The trapdoor has a nice finish in white HDF plate with hidden hinges and has high quality lock. Its floor/ceiling height is up to 278 cm.
FIRE PRO REI 45 Loft ladder is made in a solid quality of pine with 12 non-slip beech treads with black non-slip plastic feet to protect the flooring. The 19 cm high casing comes with sealing strips to prevent heat loss. The wooden ladder is easy to operate, high quality, stable and easy to use.
The loft ladder as a fireproof part – FIRE PRO REI45
It is important that a house is built so that the structure is protected for a short time in the case of a fire. Therefore, the building regulations set several requirements regarding the fire resistance on constructions parts in a building or house. This includes a standard for loft ladders. Therefore, we test our fire-resistant loft ladder program according to the highest demands in Europe and they comply to EN 13501-2. SOGEM FIRE PRO REI45 has a fire resistance of 45 minutes.
A fire-resistant loft ladder is tested in a fire test where the loft ladder is built into a fire chamber and exposed to a real-life fire situation. SOGEM's fire-resistant loft ladders have been tested according to the new common European method for testing fire resistance for building parts REI. The fire-resistant loft ladder FIRE PRO REI45 has been tested at MPA Braunschweig institute in Germany.
Fire-resistant loft ladder - new European fire class EN 13501-2
The new European fire requirements are described from the loft ladders:
R (resistance) carrying capacity during fire.
E (integrity) ability to keep flames and gases out.
I (insulation) ability to keep warm out.
After the classification, the time for which the loft ladder can withstand fire is indicated by the FIRE PRO REI45 so that the fire-resistant loft ladders are fireproof for 45 minutes.
All loft ladders from SOGEM are tested in accordance with EN 14975.
Technical data
|
1
|
Please select a variant |
|---|---|
|
2
|
Please select a variant |
|
3
|
Please select a variant |
|
4
|
Please select a variant |
| Product number | Please select a variant |
| EAN | Please select a variant |
| Finish | White |
| Opening size (length) | Please select a variant |
| Opening size (width) | Please select a variant |
| Floor-to-ceiling height | Please select a variant |
| Total going | Please select a variant |
| Swing clearance | Please select a variant |
| Horizontal clearance | Please select a variant |
| U-value (W/m²* K) | 0.9600 |
| Attic ladder type | Folding ladder |
| Usage | Manual |
| Sections | Please select a variant |
| Ladder material | Wood |
| Trapdoor material | Sandwich construction |
| Trapdoor thickness | 56 mm |
| Insulation | 50 mm |
| Casing material | Blockboard |
| Casing thickness | 18 mm |
| Outside casing (length) | Please select a variant |
| Outside casing (width) | Please select a variant |
| Casing (height) | Please select a variant |
| Number of treads | Please select a variant |
| Tread rise | 235 mm |
| Tread material | Solid beech |
| Tread thickness | 17.5 mm |
| Tread width | Please select a variant |
| Tread depth | 83 mm |
| String material | Pine |
| String thickness | 21 mm |
| String depth | 83 mm |
| Width | 400 mm |
| Maximum load | 150 kg |
| Product weight | Please select a variant |
| Tested | U-value - tested as building component by testinstitute: IFT Rosenheim, Airtight EN 12207 class 4, EN 1026:2016, FSC® certified wood |
